• Up to 10 degrees misalignment
• Resilient Design
• Absorbs Vibration
• Exposed and shrouded bolt configurations

Technical Specifications

Bore Type	Plain Bore
Coupling Size	502
Stock Bore (in)	0.5 in
Max Bore w/SS at 180° to KW (in)	1.5 in
Max. Bore w/SS over KW (in)	1.25 in
Flange Type	Round
Torque Rating (in-lb)	1,008 in/lbs
Coupling Type	Elastomeric Coupling
Measurement System	Imperial
Lube/Non-Lube	Non-Lubricated
Speed Max (rpm)	5,300 rpm
Torque Rating (ft-lb)	84 ft/lbs
Bore Size Min (in)	0.5 in

General Specifications

UPC	662288372042
Weight	2.53 LB
Packaged Length	4.60 IN
Packaged Width	4.20 IN
Packaged Height	1.90 IN
HTC	8483.90.8010
Country of Origin	Taiwan, Republic of China
