• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.375 in
Chain Construction	Riveted
Roller Diameter (in)	0.4 in
Material	Steel
Chain Family	50
Pin Diameter (in)	0.2 in
Number of Strands/Width	4
Number of Connecting Links Included	1
Chain Type	Standard
Product Type	Roller Chain
Chain Pitch (in)	0.625 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	0.584 in
Transverse Pitch (in)	0.713 in
Width Over Pins/Total Width (in)	2.933 in
Pin Length (in)	2.933 in
Plate Thickness (in)	0.08 in
Base Catalog No	50-4
Minimum Tensile Strength (lbs)	19,528 lb
Side Plate Configuration	Hourglass
Total Length (ft)	10 ft

General Specifications

UPC	662288455332
Weight	2.74 LB
Packaged Length	9.60 IN
Packaged Width	9.60 IN
Packaged Height	3.40 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
