• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Number of Strands/Width	2
Chain Family	50
Pin Diameter (in)	0.2 in
Number of Connecting Links Included	5
Roller Diameter (in)	0.4 in
Chain Construction	Riveted
Roller Width (in)	0.375 in
Product Type	Roller Chain
Chain Pitch (in)	0.625 in
Chain Type	Standard
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Minimum Tensile Strength (lbs)	9,764 lb
Inside Plate Height (in)	0.584 in
Total Length (ft)	50 ft
Base Catalog No	50-2
Pin Length (in)	1.507 in
Plate Thickness (in)	0.08 in
Side Plate Configuration	Hourglass
Transverse Pitch (in)	0.713 in
Width Over Pins/Total Width (in)	1.507 in

General Specifications

UPC	662288467915
Weight	1.49 LB
Packaged Length	14.00 IN
Packaged Width	13.90 IN
Packaged Height	14.20 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
