• Unmatched Quality and Performance in Morse Brand Chain
• 304 Series Stainless Steel for the most corrosive environments
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.3125 in
Chain Family	40
Roller Diameter (in)	0.312 in
Chain Construction	Riveted
Number of Strands/Width	1
Pin Diameter (in)	0.156 in
Number of Connecting Links Included	1
Material	Stainless Steel
Chain Pitch (in)	0.5 in
Chain Type	Stainless Steel
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Plate Thickness (in)	0.06 in
Inside Plate Height (in)	0.466 in
Total Length (ft)	10 ft
Width Over Pins/Total Width (in)	0.63 in
Side Plate Configuration	Hourglass
Minimum Tensile Strength (lbs)	0.068 lb
Base Catalog No	40SS
Pin Length (in)	0.63 in

General Specifications

UPC	662288791195
Weight	0.43 LB
Packaged Length	7.60 IN
Packaged Width	7.80 IN
Packaged Height	1.30 IN
HTC	7315.11.0060
Country of Origin	Japan
