• Unmatched Quality and Performance in Morse Brand Chain
• 304 Series Stainless Steel for the most corrosive environments
• Available from Stock

Technical Specifications

Pin Diameter (in)	0.156 in
Number of Strands/Width	1
Roller Diameter (in)	0.312 in
Roller Width (in)	0.3125 in
Material	Stainless Steel
Chain Size	40
Chain Pitch (in)	0.5 in
Chain Type	Stainless Steel
Product Type	Roller Chain
Link Type	Offset Link
Side Plate Configuration	Hourglass
Inside Plate Height (in)	0.466 in
Plate Thickness (in)	0.06 in
Overall Width/Pin Length (in)	0.63 in

General Specifications

UPC	662288801795
Weight	0.45 LB
Packaged Length	2.95 IN
Packaged Width	1.10 IN
Packaged Height	0.65 IN
HTC	7315.19.0000
Country of Origin	Japan
