• Unmatched Quality and Performance in Morse Brand Chain
• Roller chain with the self-lubricating properties of oil impregnated, sintered metal bushings to assure longer, more reliable chain service where external lubrication is prohibited or severely limited.
• Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Number of Strands/Width	1
Roller Diameter (in)	0.312 in
Number of Connecting Links Included	5
Chain Construction	Riveted
Pin Diameter (in)	0.156 in
Roller Width (in)	0.3125 in
Chain Family	40
Product Type	Roller Chain
Chain Pitch (in)	0.5 in
Chain Type	Sintered Bushing
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Total Length (ft)	50 ft
Side Plate Configuration	Hourglass
Inside Plate Height (in)	0.466 in
Base Catalog No	40LL
Pin Length (in)	0.63 in
Width Over Pins/Total Width (in)	0.63 in
Plate Thickness (in)	0.06 in

General Specifications

UPC	662288400394
Weight	0.45 LB
Packaged Length	9.10 IN
Packaged Width	9.10 IN
Packaged Height	9.30 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
