• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Connecting Links Included	1
Number of Strands/Width	3
Chain Construction	Riveted
Chain Family	40
Material	Steel
Roller Diameter (in)	0.312 in
Pin Diameter (in)	0.156 in
Roller Width (in)	0.3125 in
Product Type	Roller Chain
Chain Type	Standard
Chain Pitch (in)	0.5 in
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Side Plate Configuration	Hourglass
Total Length (ft)	10 ft
Plate Thickness (in)	0.06 in
Inside Plate Height (in)	0.466 in
Minimum Tensile Strength (lbs)	9,375 lb
Base Catalog No	40-3
Width Over Pins/Total Width (in)	1.78 in
Pin Length (in)	1.78 in
Transverse Pitch (in)	0.566 in

General Specifications

UPC	662288455295
Weight	1.27 LB
Packaged Length	10.80 IN
Packaged Width	10.80 IN
Packaged Height	2.40 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
