• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.3125 in
Chain Family	40
Pin Diameter (in)	0.156 in
Chain Construction	Riveted
Roller Diameter (in)	0.312 in
Number of Connecting Links Included	1
Number of Strands/Width	2
Material	Steel
Chain Pitch (in)	0.5 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Plate Thickness (in)	0.06 in
Minimum Tensile Strength (lbs)	6,250 lb
Total Length (ft)	10 ft
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	1.215 in
Base Catalog No	40-2
Transverse Pitch (in)	0.566 in
Pin Length (in)	1.215 in
Inside Plate Height (in)	0.466 in

General Specifications

UPC	662288395089
Weight	0.90 LB
Packaged Length	9.30 IN
Packaged Width	8.90 IN
Packaged Height	1.60 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
