• Unmatched Quality and Performance in Morse Brand Chain
• 304 Series Stainless Steel for the most corrosive environments
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Strands/Width	1
Pin Diameter (in)	0.141 in
Roller Diameter (in)	0.2 in
Roller Width (in)	0.1875 in
Material	Stainless Steel
Number of Connecting Links Included	1
Chain Family	35
Chain Construction	Riveted
Chain Type	Stainless Steel
Chain Pitch (in)	0.375 in
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Width Over Pins/Total Width (in)	0.466 in
Minimum Tensile Strength (lbs)	0.041 lb
Side Plate Configuration	Hourglass
Inside Plate Height (in)	0.35 in
Plate Thickness (in)	0.05 in
Pin Length (in)	0.466 in
Base Catalog No	35SS
Total Length (ft)	10 ft

General Specifications

UPC	662288791188
Weight	0.28 LB
Packaged Length	7.00 IN
Packaged Width	7.00 IN
Packaged Height	1.10 IN
HTC	7315.11.0060
Country of Origin	Japan
