• Up to 10 degrees misalignment
• Resilient Design
• Absorbs Vibration
• Exposed and shrouded bolt configurations

Technical Specifications

Bore Type	Plain Bore
Stock Bore (in)	0.75 in
Coupling Size	352
Max. Bore w/SS over KW (in)	0.875 in
Max Bore w/SS at 180° to KW (in)	1 in
Flange Type	Oval
Coupling Type	Elastomeric Coupling
Lube/Non-Lube	Non-Lubricated
Torque Rating (in-lb)	384 in/lbs
Measurement System	Imperial
Speed Max (rpm)	5,500 rpm
Torque Rating (ft-lb)	32 ft/lbs
Bore Size Min (in)	0.375 in

General Specifications

UPC	662288371700
Weight	0.62 LB
Packaged Length	3.20 IN
Packaged Width	3.30 IN
Packaged Height	1.40 IN
HTC	8483.90.8010
Country of Origin	Taiwan, Republic of China
