• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.1875 in
Chain Construction	Riveted
Pin Diameter (in)	0.141 in
Material	Steel
Number of Strands/Width	4
Chain Family	35
Roller Diameter (in)	0.2 in
Number of Connecting Links Included	1
Chain Pitch (in)	0.375 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Total Length (ft)	10 ft
Base Catalog No	35-4
Pin Length (in)	1.664 in
Minimum Tensile Strength (lbs)	7,032 lb
Side Plate Configuration	Hourglass
Transverse Pitch (in)	0.399 in
Inside Plate Height (in)	0.35 in
Plate Thickness (in)	0.05 in
Width Over Pins/Total Width (in)	1.664 in

General Specifications

UPC	662288459736
Weight	0.91 LB
Packaged Length	9.10 IN
Packaged Width	8.90 IN
Packaged Height	2.00 IN
HTC	7315.11.0060
Country of Origin	Japan
