• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Connecting Links Included	1
Chain Construction	Riveted
Pin Diameter (in)	0.141 in
Roller Diameter (in)	0.2 in
Roller Width (in)	0.1875 in
Number of Strands/Width	2
Chain Family	35
Material	Steel
Chain Pitch (in)	0.375 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Minimum Tensile Strength (lbs)	3,516 lb
Width Over Pins/Total Width (in)	0.866 in
Transverse Pitch (in)	0.399 in
Pin Length (in)	0.866 in
Plate Thickness (in)	0.05 in
Inside Plate Height (in)	0.35 in
Base Catalog No	35-2
Side Plate Configuration	Hourglass
Total Length (ft)	10 ft

General Specifications

UPC	662288390848
Weight	0.48 LB
Packaged Length	7.50 IN
Packaged Width	7.70 IN
Packaged Height	1.10 IN
HTC	7315.11.0060
Country of Origin	Japan
