• Unmatched Quality and Performance in Morse Brand Chain
• 304 Series Stainless Steel for the most corrosive environments
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Connecting Links Included	1
Roller Width (in)	0.125 in
Material	Stainless Steel
Chain Construction	Riveted
Number of Strands/Width	1
Pin Diameter (in)	0.091 in
Roller Diameter (in)	0.13 in
Chain Family	25
Chain Type	Stainless Steel
Product Type	Roller Chain
Chain Pitch (in)	0.25 in
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Base Catalog No	25SS
Width Over Pins/Total Width (in)	0.312 in
Side Plate Configuration	Hourglass
Minimum Tensile Strength (lbs)	0.017 lb
Inside Plate Height (in)	0.23 in
Total Length (ft)	10 ft
Plate Thickness (in)	0.03 in
Pin Length (in)	0.312 in

General Specifications

UPC	662288713524
Weight	0.14 LB
Packaged Length	5.60 IN
Packaged Width	5.40 IN
Packaged Height	0.70 IN
HTC	7315.11.0060
Country of Origin	Japan
