• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Strands/Width	1
Roller Width (in)	1.5 in
Chain Construction	Cottered
Number of Connecting Links Included	1
Roller Diameter (in)	1.562 in
Material	Steel
Chain Family	200
Pin Diameter (in)	0.781 in
Chain Pitch (in)	2.5 in
Chain Type	Heavy
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Width Over Pins/Total Width (in)	3.374 in
Side Plate Configuration	Hourglass
Plate Thickness (in)	0.375 in
Total Length (ft)	10 ft
Base Catalog No	200H
Pin Length (in)	3.374 in
Inside Plate Height (in)	2.334 in

General Specifications

UPC	662288455851
Weight	12.30 LB
Packaged Length	18.50 IN
Packaged Width	18.50 IN
Packaged Height	4.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
