• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Diameter (in)	1.562 in
Chain Construction	Riveted
Chain Family	200
Number of Connecting Links Included	1
Pin Diameter (in)	0.781 in
Material	Steel
Roller Width (in)	1.5 in
Number of Strands/Width	3
Chain Pitch (in)	2.5 in
Product Type	Roller Chain
Chain Type	Standard
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Transverse Pitch (in)	2.817 in
Minimum Tensile Strength (lbs)	234,375 lb
Inside Plate Height (in)	2.25 in
Pin Length (in)	8.754 in
Width Over Pins/Total Width (in)	8.754 in
Total Length (ft)	10 ft
Side Plate Configuration	Hourglass
Plate Thickness (in)	0.312 in
Base Catalog No	200-3

General Specifications

UPC	662288860174
Weight	32.04 LB
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
