• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Strands/Width	2
Roller Diameter (in)	1.562 in
Material	Steel
Chain Family	200
Roller Width (in)	1.5 in
Chain Construction	Riveted
Number of Connecting Links Included	1
Pin Diameter (in)	0.781 in
Chain Pitch (in)	2.5 in
Product Type	Roller Chain
Chain Type	Standard
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Minimum Tensile Strength (lbs)	156,250 lb
Transverse Pitch (in)	2.817 in
Pin Length (in)	5.937 in
Width Over Pins/Total Width (in)	5.937 in
Inside Plate Height (in)	2.25 in
Total Length (ft)	10 ft
Plate Thickness (in)	0.312 in
Side Plate Configuration	Hourglass
Base Catalog No	200-2

General Specifications

UPC	662288455622
Weight	21.51 LB
Packaged Length	19.00 IN
Packaged Width	19.00 IN
Packaged Height	6.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
