• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Pin Diameter (in)	0.781 in
Chain Construction	Cottered
Roller Width (in)	1.5 in
Roller Diameter (in)	1.562 in
Number of Strands/Width	2
Number of Connecting Links Included	1
Chain Family	200
Chain Pitch (in)	2.5 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	2.25 in
Pin Length (in)	5.937 in
Minimum Tensile Strength (lbs)	156,250 lb
Plate Thickness (in)	0.312 in
Base Catalog No	200-2
Total Length (ft)	10 ft
Width Over Pins/Total Width (in)	5.937 in
Side Plate Configuration	Hourglass
Transverse Pitch (in)	2.817 in

General Specifications

UPC	662288455639
Weight	21.50 LB
Packaged Length	18.50 IN
Packaged Width	19.00 IN
Packaged Height	7.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
