• Unmatched Quality and Performance in Morse Brand Chain
• High Quality British Standard Metric chain
• British standard chain is manufactured to International Standards

Technical Specifications

Pin Diameter (mm)	8.26 mm
Roller Width (mm)	17.02 mm
Chain Construction	Riveted
Chain Family	16
Number of Strands/Width	3
Roller Diameter (mm)	15.88 mm
Material	Steel
Product Type	Roller Chain
Chain Pitch (in)	1 in
Chain Type	British Standard
Roller Diameter (in)	0.6252 in
Pin Diameter (in)	0.3252 in
Roller Width (in)	0.67 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Metric
Inside Plate Height (in)	0.81496062992126 in
Connecting Link	Spring Clip
Total Length (ft)	10 ft
Plate Thickness (in)	1 in
Width Over Pins/Total Width (in)	4.09055118110236 in
Pin Length (in)	4.0906 in
Base Catalog No	16B-3
Transverse Pitch (in)	1.255 in

General Specifications

UPC	662460388540
Weight	5.50 LB
Packaged Length	12.00 IN
Packaged Width	11.90 IN
Packaged Height	6.70 IN
HTC	7315.11.0060
Country of Origin	China
