• Unmatched Quality and Performance in Morse Brand Chain
• High Quality British Standard Metric chain
• British standard chain is manufactured to International Standards

Technical Specifications

Chain Family	16
Roller Width (mm)	17.02 mm
Number of Strands/Width	1
Chain Construction	Riveted
Pin Diameter (mm)	8.26 mm
Roller Diameter (mm)	15.88 mm
Material	Steel
Product Type	Roller Chain
Chain Type	British Standard
Chain Pitch (in)	1 in
Roller Width (in)	0.67 in
Roller Diameter (in)	0.6252 in
Pin Diameter (in)	0.3252 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Metric
Inside Plate Height (in)	0.81496062992126 in
Plate Thickness (in)	1 in
Connecting Link	Spring Clip
Base Catalog No	16B-1
Pin Length (in)	1.5512 in
Width Over Pins/Total Width (in)	1.5511811023622 in
Total Length (ft)	10 ft

General Specifications

UPC	662460388489
Weight	1.88 LB
Packaged Length	11.30 IN
Packaged Width	11.10 IN
Packaged Height	1.60 IN
HTC	7315.11.0060
Country of Origin	China
