• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Pin Diameter (in)	0.562 in
Roller Diameter (in)	1.125 in
Roller Width (in)	1.25 in
Number of Strands/Width	1
Chain Family	160
Chain Construction	Cottered
Number of Connecting Links Included	1
Material	Steel
Product Type	Roller Chain
Chain Type	Standard
Chain Pitch (in)	2 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	1.866 in
Side Plate Configuration	Hourglass
Pin Length (in)	2.522 in
Plate Thickness (in)	0.25 in
Total Length (ft)	10 ft
Minimum Tensile Strength (lbs)	50,000 lb
Base Catalog No	160
Width Over Pins/Total Width (in)	2.522 in

General Specifications

UPC	662288395331
Weight	6.61 LB
Packaged Length	17.25 IN
Packaged Width	17.25 IN
Packaged Height	3.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
