• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Pin Diameter (in)	0.563 in
Number of Connecting Links Included	1
Number of Strands/Width	2
Roller Width (in)	1.25 in
Chain Family	160
Chain Construction	Cottered
Material	Steel
Roller Diameter (in)	1.125 in
Chain Pitch (in)	2 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Plate Thickness (in)	0.25 in
Inside Plate Height (in)	1.81 in
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	4.827 in
Pin Length (in)	4.827 in
Base Catalog No	160-2
Transverse Pitch (in)	2.035 in
Minimum Tensile Strength (lbs)	100,000 lb
Total Length (ft)	10 ft

General Specifications

UPC	662288455608
Weight	12.91 LB
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
