• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Connecting Links Included	1
Number of Strands/Width	1
Material	Steel
Roller Width (in)	1 in
Pin Diameter (in)	0.5 in
Chain Family	140
Roller Diameter (in)	1 in
Chain Construction	Riveted
Chain Pitch (in)	1.75 in
Product Type	Roller Chain
Chain Type	Standard
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Base Catalog No	140
Pin Length (in)	2.117 in
Width Over Pins/Total Width (in)	2.117 in
Plate Thickness (in)	0.219 in
Inside Plate Height (in)	1.634 in
Total Length (ft)	10.21 ft
Side Plate Configuration	Hourglass
Minimum Tensile Strength (lbs)	38,280 lb

General Specifications

UPC	662288395324
Weight	5.15 LB
Packaged Length	16.00 IN
Packaged Width	15.90 IN
Packaged Height	2.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
