• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Construction	Cottered
Pin Diameter (in)	0.5 in
Material	Steel
Number of Connecting Links Included	1
Roller Diameter (in)	1 in
Number of Strands/Width	1
Roller Width (in)	1 in
Chain Family	140
Chain Type	Standard
Product Type	Roller Chain
Chain Pitch (in)	1.75 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Minimum Tensile Strength (lbs)	38,280 lb
Width Over Pins/Total Width (in)	2.117 in
Side Plate Configuration	Hourglass
Inside Plate Height (in)	1.634 in
Base Catalog No	140
Total Length (ft)	10.21 ft
Plate Thickness (in)	0.219 in
Pin Length (in)	2.117 in

General Specifications

UPC	662288395317
Weight	5.26 LB
Packaged Length	16.10 IN
Packaged Width	15.90 IN
Packaged Height	2.80 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
