• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Strands/Width	3
Pin Diameter (in)	0.5 in
Chain Construction	Cottered
Roller Diameter (in)	1 in
Number of Connecting Links Included	1
Material	Steel
Chain Family	140
Roller Width (in)	1 in
Chain Pitch (in)	1.75 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Pin Length (in)	5.965 in
Total Length (ft)	10.21 ft
Transverse Pitch (in)	1.924 in
Plate Thickness (in)	0.219 in
Base Catalog No	140-3
Minimum Tensile Strength (lbs)	114,840 lb
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	5.965 in
Inside Plate Height (in)	1.56 in

General Specifications

UPC	662288455578
Weight	14.63 LB
Packaged Length	19.00 FT
Packaged Width	16.00 FT
Packaged Height	8.00 FT
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
