• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Number of Strands/Width	2
Roller Diameter (in)	1 in
Chain Construction	Riveted
Pin Diameter (in)	0.5 in
Chain Family	140
Number of Connecting Links Included	1
Roller Width (in)	1 in
Product Type	Roller Chain
Chain Pitch (in)	1.75 in
Chain Type	Standard
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Minimum Tensile Strength (lbs)	76,560 lb
Base Catalog No	140-2
Inside Plate Height (in)	1.56 in
Plate Thickness (in)	0.219 in
Transverse Pitch (in)	1.924 in
Pin Length (in)	4.041 in
Total Length (ft)	10.21 ft
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	4.041 in

General Specifications

UPC	662288455547
Weight	9.80 LB
Packaged Length	15.75 IN
Packaged Width	19.00 IN
Packaged Height	5.25 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
