• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Construction	Cottered
Material	Steel
Number of Strands/Width	2
Number of Connecting Links Included	1
Pin Diameter (in)	0.5 in
Roller Diameter (in)	1 in
Roller Width (in)	1 in
Chain Family	140
Chain Type	Standard
Product Type	Roller Chain
Chain Pitch (in)	1.75 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Transverse Pitch (in)	1.924 in
Total Length (ft)	10.21 ft
Side Plate Configuration	Hourglass
Base Catalog No	140-2
Plate Thickness (in)	0.219 in
Pin Length (in)	4.041 in
Minimum Tensile Strength (lbs)	76,560 lb
Inside Plate Height (in)	1.56 in
Width Over Pins/Total Width (in)	4.041 in

General Specifications

UPC	662288455561
Weight	9.80 LB
Packaged Length	16.00 IN
Packaged Width	18.50 IN
Packaged Height	6.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
