• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Chain Construction	Riveted
Chain Family	120
Pin Diameter (in)	0.437 in
Number of Strands/Width	1
Number of Connecting Links Included	1
Roller Width (in)	1 in
Roller Diameter (in)	0.875 in
Chain Type	Standard
Chain Pitch (in)	1.5 in
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Width Over Pins/Total Width (in)	1.96 in
Pin Length (in)	1.96 in
Total Length (ft)	10 ft
Inside Plate Height (in)	1.4 in
Base Catalog No	120
Minimum Tensile Strength (lbs)	28,125 lb
Plate Thickness (in)	0.187 in
Side Plate Configuration	Hourglass

General Specifications

UPC	662288395300
Weight	3.98 LB
Packaged Length	15.10 IN
Packaged Width	14.90 IN
Packaged Height	2.20 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
