• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Chain Construction	Cottered
Roller Diameter (in)	0.875 in
Number of Connecting Links Included	1
Chain Family	120
Roller Width (in)	1 in
Number of Strands/Width	1
Pin Diameter (in)	0.438 in
Product Type	Roller Chain
Chain Type	Heavy
Chain Pitch (in)	1.5 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Pin Length (in)	2.09 in
Base Catalog No	120H
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	2.09 in
Inside Plate Height (in)	1.4 in
Total Length (ft)	10 ft
Plate Thickness (in)	0.219 in

General Specifications

UPC	662288455790
Weight	4.52 LB
Packaged Length	14.70 IN
Packaged Width	15.00 IN
Packaged Height	2.70 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
