• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Family	120
Number of Connecting Links Included	1
Roller Diameter (in)	0.875 in
Pin Diameter (in)	0.437 in
Material	Steel
Number of Strands/Width	2
Chain Construction	Riveted
Roller Width (in)	1 in
Chain Type	Heavy
Product Type	Roller Chain
Chain Pitch (in)	1.5 in
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Inside Plate Height (in)	1.4 in
Width Over Pins/Total Width (in)	4.019 in
Plate Thickness (in)	0.219 in
Total Length (ft)	10 ft
Side Plate Configuration	Hourglass
Pin Length (in)	4.019 in
Base Catalog No	120H-2
Transverse Pitch (in)	1.924 in

General Specifications

UPC	662288860235
Weight	8.40 LB
Packaged Length	16.00 IN
Packaged Width	18.75 IN
Packaged Height	5.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
