• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	1 in
Chain Family	120
Chain Construction	Cottered
Roller Diameter (in)	0.875 in
Pin Diameter (in)	0.437 in
Number of Connecting Links Included	1
Material	Steel
Number of Strands/Width	1
Chain Type	Standard
Chain Pitch (in)	1.5 in
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Width Over Pins/Total Width (in)	1.96 in
Total Length (ft)	10 ft
Plate Thickness (in)	0.187 in
Pin Length (in)	1.96 in
Minimum Tensile Strength (lbs)	28,125 lb
Inside Plate Height (in)	1.4 in
Side Plate Configuration	Hourglass
Base Catalog No	120

General Specifications

UPC	662288395294
Weight	3.99 LB
Packaged Length	14.90 IN
Packaged Width	15.00 IN
Packaged Height	2.40 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
