• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Diameter (in)	0.875 in
Roller Width (in)	1 in
Chain Construction	Riveted
Chain Family	120
Number of Strands/Width	3
Material	Steel
Number of Connecting Links Included	1
Pin Diameter (in)	0.438 in
Product Type	Roller Chain
Chain Pitch (in)	1.5 in
Chain Type	Standard
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Side Plate Configuration	Hourglass
Transverse Pitch (in)	1.789 in
Minimum Tensile Strength (lbs)	84,375 lb
Pin Length (in)	5.538 in
Plate Thickness (in)	0.187 in
Width Over Pins/Total Width (in)	5.538 in
Base Catalog No	120-3
Inside Plate Height (in)	1.4 in
Total Length (ft)	10 ft

General Specifications

UPC	662288455493
Weight	11.43 LB
Packaged Length	18.50 IN
Packaged Width	15.75 IN
Packaged Height	7.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
