• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	1 in
Chain Family	120
Roller Diameter (in)	0.875 in
Number of Strands/Width	3
Chain Construction	Cottered
Number of Connecting Links Included	1
Pin Diameter (in)	0.438 in
Material	Steel
Chain Type	Standard
Chain Pitch (in)	1.5 in
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Inside Plate Height (in)	1.4 in
Total Length (ft)	10 ft
Pin Length (in)	5.538 in
Base Catalog No	120-3
Side Plate Configuration	Hourglass
Plate Thickness (in)	0.187 in
Minimum Tensile Strength (lbs)	84,375 lb
Width Over Pins/Total Width (in)	5.538 in
Transverse Pitch (in)	1.789 in

General Specifications

UPC	662288455523
Weight	12.10 LB
Packaged Length	16.00 IN
Packaged Width	19.00 IN
Packaged Height	7.25 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
