• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Construction	Cottered
Pin Diameter (in)	0.375 in
Roller Width (in)	0.75 in
Number of Connecting Links Included	1
Roller Diameter (in)	0.75 in
Material	Steel
Chain Family	100
Number of Strands/Width	1
Product Type	Roller Chain
Chain Pitch (in)	1.25 in
Chain Type	Standard
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Inside Plate Height (in)	1.166 in
Total Length (ft)	10 ft
Base Catalog No	100
Side Plate Configuration	Hourglass
Pin Length (in)	1.555 in
Width Over Pins/Total Width (in)	1.555 in
Minimum Tensile Strength (lbs)	19,530 lb
Plate Thickness (in)	0.156 in

General Specifications

UPC	662288395270
Weight	2.83 LB
Packaged Length	13.80 IN
Packaged Width	13.60 IN
Packaged Height	1.90 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
