• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Connecting Links Included	1
Material	Steel
Chain Family	100
Chain Construction	Riveted
Pin Diameter (in)	0.375 in
Number of Strands/Width	5
Roller Diameter (in)	0.75 in
Roller Width (in)	0.75 in
Product Type	Roller Chain
Chain Type	Standard
Chain Pitch (in)	1.25 in
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Inside Plate Height (in)	1.166 in
Transverse Pitch (in)	1.408 in
Pin Length (in)	7.187 in
Total Length (ft)	10 ft
Plate Thickness (in)	0.156 in
Base Catalog No	100-5
Minimum Tensile Strength (lbs)	97,650 lb
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	7.187 in

General Specifications

UPC	662288865711
Weight	12.66 LB
Packaged Length	16.00 IN
Packaged Width	12.00 IN
Packaged Height	8.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
