• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Pin Diameter (in)	0.375 in
Number of Strands/Width	4
Number of Connecting Links Included	1
Material	Steel
Chain Construction	Cottered
Roller Width (in)	0.75 in
Chain Family	100
Roller Diameter (in)	0.75 in
Chain Pitch (in)	1.25 in
Product Type	Roller Chain
Chain Type	Standard
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Pin Length (in)	5.779 in
Plate Thickness (in)	0.156 in
Total Length (ft)	10 ft
Width Over Pins/Total Width (in)	5.779 in
Base Catalog No	100-4
Inside Plate Height (in)	1.166 in
Side Plate Configuration	Hourglass
Minimum Tensile Strength (lbs)	78,120 lb
Transverse Pitch (in)	1.408 in

General Specifications

UPC	662288455479
Weight	10.12 LB
Packaged Length	14.50 IN
Packaged Width	14.50 IN
Packaged Height	8.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
