• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Material	Steel
Roller Width (in)	0.75 in
Pin Diameter (in)	0.375 in
Chain Construction	Riveted
Chain Family	100
Number of Connecting Links Included	1
Roller Diameter (in)	0.75 in
Number of Strands/Width	2
Chain Type	Standard
Product Type	Roller Chain
Chain Pitch (in)	1.25 in
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Pin Length (in)	2.963 in
Total Length (ft)	10 ft
Transverse Pitch (in)	1.408 in
Width Over Pins/Total Width (in)	2.963 in
Minimum Tensile Strength (lbs)	39,060 lb
Plate Thickness (in)	0.156 in
Inside Plate Height (in)	1.166 in
Base Catalog No	100-2
Side Plate Configuration	Hourglass

General Specifications

UPC	662288455424
Weight	5.35 LB
Packaged Length	14.00 IN
Packaged Width	13.80 IN
Packaged Height	3.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
