• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.75 in
Number of Connecting Links Included	1
Chain Construction	Cottered
Number of Strands/Width	2
Material	Steel
Pin Diameter (in)	0.375 in
Roller Diameter (in)	0.75 in
Chain Family	100
Product Type	Roller Chain
Chain Type	Standard
Chain Pitch (in)	1.25 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Transverse Pitch (in)	1.408 in
Side Plate Configuration	Hourglass
Base Catalog No	100-2
Plate Thickness (in)	0.156 in
Total Length (ft)	10 ft
Inside Plate Height (in)	1.166 in
Pin Length (in)	2.963 in
Width Over Pins/Total Width (in)	2.963 in
Minimum Tensile Strength (lbs)	39,060 lb

General Specifications

UPC	662288455455
Weight	5.42 LB
Packaged Length	13.80 IN
Packaged Width	13.80 IN
Packaged Height	3.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
