• Unmatched Quality and Performance in Morse Brand Chain
• High Quality British Standard Metric chain
• British standard chain is manufactured to International Standards

Technical Specifications

Pin Diameter (mm)	4.45 mm
Chain Construction	Riveted
Chain Family	08
Number of Strands/Width	3
Roller Diameter (mm)	8.51 mm
Roller Width (mm)	7.75 mm
Material	Steel
Product Type	Roller Chain
Chain Type	British Standard
Chain Pitch (in)	0.5 in
Roller Diameter (in)	0.335 in
Coating	Uncoated
Roller Width (in)	0.3051 in
Pin Diameter (in)	0.1752 in
Measurement System	Metric
Standard Met	ANSI B29.1
Transverse Pitch (in)	0.653 in
Base Catalog No	08B-3
Inside Plate Height (in)	0.464566929133858 in
Pin Length (in)	1.8583 in
Plate Thickness (in)	0.445 in
Connecting Link	Spring Clip
Total Length (ft)	25 ft
Width Over Pins/Total Width (in)	1.85826771653543 in

General Specifications

UPC	662460388229
Weight	1.36 LB
Packaged Length	13.50 IN
Packaged Width	13.60 IN
Packaged Height	2.20 IN
HTC	7315.11.0060
Country of Origin	China
