• Stud type cam follower
• V-grooved outside diameter
• Ball bearing insert
• Hex hole on thread face

Dimensions

Threads	3/4-16
Point Diameter (in)	1.5 in
Roller Diameter (in)	2.5 in
Stud Diameter (in)	0.75 in
Stud Length (in)	1.75 in
Hex Socket (in)	0.25 in
Roller Width (in)	1.3125 in
Weight (kg)	0.57 kg

Technical Specifications

Rolling Element	Ball (TRAKROL)
Sealing	Sealed
Limiting Speed	2,500
Dynamic Radial Rating	2,520
Adjustment	None
Series	TRAKROL®
Hex/Slot	Hex Hole
O.D. Configuration	V Groove
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud
Roller Shape	V Groove
Dynamic Load Rating - both bearings	2,520
Dynamic Load Rating (lb)	2,520 lb
Static Load Rating	1,370
Tolerance Class	P0 Equivalent
Dynamic Load Rating - single bearing	1,530
Platform	TRAKROL®
Ability to Relubricate	No
Clamping Torque (in-lbf)	625 lbs

General Specifications

UPC	726166111373
Weight	1.25 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.10.5064
Country of Origin	Mexico
