• Stud type cam follower
• Cylindrical outside diameter
• Ball bearing insert
• Hex hole on thread face

Dimensions

Threads	5/8-18
Roller Diameter (in)	1.5 in
Stud Diameter (in)	0.625 in
Minimum Thread Length (in)	0.75 in
Roller Width (in)	1.1875 in
Hex Socket (in)	0.25 in
Stud Length (in)	1.5 in
Weight (kg)	0.24 kg

Technical Specifications

Limiting Speed	2,500
Rolling Element	Ball (TRAKROL)
Dynamic Radial Rating	2,520
Series	TRAKROL®
O.D. Configuration	Cylindrical
Sealing	Sealed
Hex/Slot	Hex Hole
Adjustment	None
Material	Bearing Steel, Black Oxide Finish
Dynamic Load Rating (lb)	2,520 lb
Static Load Rating	1,370
Tolerance Class	P0 Equivalent
Dynamic Load Rating - both bearings	2,520
Platform	TRAKROL®
Dynamic Load Rating - single bearing	1,530
Roller Shape	Cylindrical
Stud Type	Standard Stud
Ability to Relubricate	No
Clamping Torque (in-lbf)	325 lbs

General Specifications

UPC	726166035983
Weight	0.53 LB
Packaged Length	1.68 IN
Packaged Width	1.68 IN
Packaged Height	2.62 IN
HTC	8482.10.5064
Country of Origin	Mexico
