• Stud type cam follower
• Flanged outside diameter
• Tapered bearing insert
• Hex hole on thread face

Dimensions

Threads	1 1/4-12
Roller Diameter (in)	4.5 in
Roller Width (in)	2 in
Stud Length (in)	2.75 in
Stud Diameter (in)	1.25 in
Hex Socket (in)	0.4375 in
Weight (kg)	4.44 kg

Technical Specifications

Rolling Element	Tapered Roller (TRAKROL)
Limiting Speed	625
Series	TRAKROL®
Hex/Slot	Hex Hole
O.D. Configuration	Flanged
Adjustment	None
Sealing	Sealed
Dynamic Radial Rating	14,300
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0 Equivalent
Static Load Rating	16,000
Platform	TRAKROL®
Dynamic Load Rating (lb)	14,300 lb
Roller Shape	Flanged
Dynamic Load Rating - both bearings	14,300
Dynamic Load Rating - single bearing	7,430
Stud Type	Standard Stud
Clamping Torque (in-lbf)	1,720 lbs
Ability to Relubricate	No

General Specifications

UPC	726166041311
Weight	9.78 LB
Packaged Length	5.50 IN
Packaged Width	5.50 IN
Packaged Height	4.75 IN
