• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole
• Heavy stud configuration

Dimensions

Threads	5/16-24
Roller Diameter (in)	0.625 in
Stud Length (in)	0.75 in
Minimum Thread Length (in)	0.31 in
Stud Diameter (in)	0.3125 in
Lubrication Fitting Size (mm)	1/8 mm
Lubrication Fitting Size (in)	1/8 in
Roller Width (in)	0.4375 in
Weight (kg)	0.02 kg

Technical Specifications

Sealing	Unsealed
Series	Inch CAMROL®
O.D. Configuration	Cylindrical
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Screwdriver Slot
Adjustment	None
Limiting Speed	9,200
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Dynamic Load Rating (lb)	955 lb
Roller Shape	Cylindrical
Tolerance Class	P0 Equivalent
Stud Type	Heavy Stud
Static Load Rating	1,000
Clamping Torque (in-lbf)	90 lbs
Ability to Relubricate	No

General Specifications

UPC	726166031084
Weight	0.05 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
