• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Heavy stud configuration

Dimensions

Threads	1 1/2-12
Roller Diameter (in)	3 in
Stud Length (in)	2.5 in
Stud Diameter (in)	1.5 in
Minimum Thread Length (in)	1.25 in
Roller Width (in)	1.75 in
Oil Hole Center (in)	0.625 in
Oil Hole Diameter (in)	0.125 in
Lubrication Fitting Size (mm)	1/4 mm
Lubrication Fitting Size (in)	1/4 in
Weight (kg)	1.95 kg

Technical Specifications

Limiting Speed	950
Hex/Slot	Hex Hole
Sealing	Sealed
Adjustment	None
Series	Inch CAMROL®
O.D. Configuration	Cylindrical
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	31,500
Dynamic Load Rating (lb)	15,720 lb
Roller Shape	Cylindrical
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Stud Type	Heavy Stud
Clamping Torque (in-lbf)	5,000 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166039233
Weight	4.29 LB
Packaged Length	3.25 IN
Packaged Width	3.25 IN
Packaged Height	4.50 IN
HTC	8482.40.0000
Country of Origin	Mexico
