• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole
• LUBRI-DISC® seal
• Heavy stud configuration

Dimensions

Threads	1 1/2-12
Roller Diameter (in)	3 in
Minimum Thread Length (in)	1.25 in
Lubrication Fitting Size (mm)	1/4 mm
Stud Length (in)	2.5 in
Lubrication Fitting Size (in)	1/4 in
Roller Width (in)	1.75 in
Oil Hole Diameter (in)	0.125 in
Stud Diameter (in)	1.5 in
Oil Hole Center (in)	0.625 in
Weight (kg)	1.99 kg

Technical Specifications

Adjustment	None
Sealing	Sealed
Limiting Speed	950
O.D. Configuration	Cylindrical
Series	Inch CAMROL®
Hex/Slot	Screwdriver Slot
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Stud Type	Heavy Stud
Tolerance Class	P0 Equivalent
Static Load Rating	31,500
Dynamic Load Rating (lb)	15,720 lb
Roller Shape	Cylindrical
Clamping Torque (in-lbf)	5,000 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166039226
Weight	4.38 LB
Packaged Length	3.25 IN
Packaged Width	3.25 IN
Packaged Height	4.50 IN
HTC	8482.40.0000
Country of Origin	Mexico
