• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Heavy stud configuration

Dimensions

Threads	1 1/8-12
Roller Diameter (in)	2.25 in
Oil Hole Diameter (in)	0.125 in
Stud Length (in)	2 in
Oil Hole Center (in)	0.5 in
Minimum Thread Length (in)	1 in
Lubrication Fitting Size (mm)	3/16 mm
Roller Width (in)	1.25 in
Stud Diameter (in)	1.125 in
Lubrication Fitting Size (in)	3/16 in
Weight (kg)	0.84 kg

Technical Specifications

Sealing	Sealed
O.D. Configuration	Cylindrical
Adjustment	None
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Hex Hole
Series	Inch CAMROL®
Limiting Speed	1,300
Material	Bearing Steel, Black Oxide Finish
Stud Type	Heavy Stud
Platform	CAMROL®
Roller Shape	Cylindrical
Static Load Rating	17,600
Dynamic Load Rating (lb)	8,090 lb
Tolerance Class	P0 Equivalent
Clamping Torque (in-lbf)	2,800 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166038045
Weight	1.85 LB
Packaged Length	2.31 IN
Packaged Width	2.31 IN
Packaged Height	3.43 IN
HTC	8482.40.0000
Country of Origin	Mexico
