• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	5/16-24
Roller Diameter (in)	0.625 in
Stud Diameter (in)	0.3125 in
Minimum Thread Length (in)	0.31 in
Stud Length (in)	0.75 in
Roller Width (in)	0.4375 in
Weight (kg)	0.02 kg

Technical Specifications

O.D. Configuration	Crowned
Rolling Element	Needle Roller - Full Complement
Adjustment	None
Sealing	Sealed
Hex/Slot	Hex Hole
Series	Inch CAMROL®
Limiting Speed	9,200
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	1,000
Roller Shape	Crowned
Stud Type	Heavy Stud
Platform	CAMROL®
Dynamic Load Rating (lb)	955 lb
Tolerance Class	P0 Equivalent
Ability to Relubricate	No
Clamping Torque (in-lbf)	90 lbs

General Specifications

UPC	726166031398
Weight	0.05 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
