• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	7/16-20
Roller Diameter (in)	0.75 in
Stud Length (in)	0.875 in
Oil Hole Center (in)	0.25 in
Roller Width (in)	0.5 in
Minimum Thread Length (in)	0.38 in
Oil Hole Diameter (in)	0.094 in
Stud Diameter (in)	0.4375 in
Lubrication Fitting Size (mm)	3/16 mm
Lubrication Fitting Size (in)	3/16 in
Weight (kg)	0.04 kg

Technical Specifications

Adjustment	None
Series	Inch CAMROL®
O.D. Configuration	Crowned
Sealing	Sealed
Limiting Speed	6,400
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Hex Hole
Material	Bearing Steel, Black Oxide Finish
Stud Type	Heavy Stud
Dynamic Load Rating (lb)	1,660 lb
Tolerance Class	P0 Equivalent
Roller Shape	Crowned
Static Load Rating	2,100
Platform	CAMROL®
Ability to Relubricate	No
Clamping Torque (in-lbf)	250 lbs

General Specifications

UPC	726166032401
Weight	0.08 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
