• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	1 1/2-12
Roller Diameter (in)	3.25 in
Stud Length (in)	2.5 in
Oil Hole Center (in)	0.625 in
Oil Hole Diameter (in)	0.125 in
Minimum Thread Length (in)	1.25 in
Roller Width (in)	1.75 in
Lubrication Fitting Size (mm)	1/4 mm
Stud Diameter (in)	1.5 in
Lubrication Fitting Size (in)	1/4 in
Weight (kg)	2.26 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Limiting Speed	880
Series	Inch CAMROL®
Hex/Slot	Hex Hole
O.D. Configuration	Crowned
Sealing	Sealed
Adjustment	None
Material	Bearing Steel, Black Oxide Finish
Stud Type	Heavy Stud
Tolerance Class	P0 Equivalent
Dynamic Load Rating (lb)	15,720 lb
Static Load Rating	31,500
Roller Shape	Crowned
Platform	CAMROL®
Ability to Relubricate	No
Clamping Torque (in-lbf)	5,000 lbs

General Specifications

UPC	726166039745
Weight	4.99 LB
Packaged Length	3.25 IN
Packaged Width	3.25 IN
Packaged Height	4.50 IN
HTC	8482.40.0000
Country of Origin	Mexico
