• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	1 1/4-12
Roller Diameter (in)	2.5 in
Minimum Thread Length (in)	1.13 in
Stud Length (in)	2.25 in
Oil Hole Diameter (in)	0.125 in
Lubrication Fitting Size (mm)	3/16 mm
Stud Diameter (in)	1.25 in
Oil Hole Center (in)	0.5625 in
Roller Width (in)	1.5 in
Lubrication Fitting Size (in)	3/16 in
Weight (kg)	1.19 kg

Technical Specifications

Sealing	Sealed
O.D. Configuration	Crowned
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Hex Hole
Series	Inch CAMROL®
Limiting Speed	1,100
Adjustment	None
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0 Equivalent
Static Load Rating	32,900
Dynamic Load Rating (lb)	11,720 lb
Roller Shape	Crowned
Platform	CAMROL®
Stud Type	Heavy Stud
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	3,450 lbs
Ability to Relubricate	No

General Specifications

UPC	726166038625
Weight	2.62 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.40.0000
Country of Origin	Mexico
