• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.375 in
Lubrication Fitting Size (mm)	3/16 mm
Oil Hole Diameter (in)	0.094 in
Roller Width (in)	0.75 in
Minimum Thread Length (in)	0.63 in
Stud Diameter (in)	0.75 in
Oil Hole Center (in)	0.3125 in
Stud Length (in)	1.25 in
Lubrication Fitting Size (in)	3/16 in
Weight (kg)	0.2 kg

Technical Specifications

Adjustment	None
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
O.D. Configuration	Crowned
Series	Inch CAMROL®
Hex/Slot	Hex Hole
Limiting Speed	2,800
Material	Bearing Steel, Black Oxide Finish
Dynamic Load Rating (lb)	3,930 lb
Static Load Rating	8,500
Tolerance Class	P0 Equivalent
Roller Shape	Crowned
Platform	CAMROL®
Stud Type	Heavy Stud
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	1,250 lbs
Ability to Relubricate	No

General Specifications

UPC	726166035235
Weight	0.44 LB
Packaged Length	1.50 IN
Packaged Width	1.75 IN
Packaged Height	2.18 IN
HTC	8482.40.0000
Country of Origin	Mexico
